720P 30fps high frame rate cmos OV9712 MJPEG&YUY2 mini pc webcam web camera android with microphone
1) 1PC 720P aluminum case usb camera with 6mm lens default (2.1/2.8/3.6/6/8/12mm lens optional)
2) 1PC 3m usb cable( 2m/1m/5m optional)
Specifications: Model ELP-USB100W05MT-BL60
Lens Size 1/4 inch
Pixel Size 3.0um X 3.0um
image area 3888 μm x 2430 μm
Max. Resolution 1280(H)X720(V)
Compression format MJPEG / YUV2(YUYV)
Resolution & frame 1280X720 [email protected] 30fps [email protected]/ [email protected] 30fps [email protected]
800X600 [email protected] [email protected]/ 640X480 [email protected] 30fps [email protected] 30fps
352X248 [email protected] [email protected] 30fps/ 320X240 [email protected] 30fps [email protected] 30fps
176X144 [email protected] [email protected] 30fps/ 160X120 [email protected] 30fps [email protected] 30fps
S/N Ratio 40dB
Dynamic Range 69dB
Sensitivity 3.7V/[email protected]
Mini illumination 0. 1lux
Shutter Type Electronic rolling shutter / Frame exposure
Connecting Port type USB2.0 High Speed(Support USB2.0 HS/FS, USB2.0 OTG)
Free Drive Protocol USB Video Class(UVC)
Adjustable parameters Brightness, Contrast, Saturation, Hue, Sharpness, Gamma,
White balance, Backlight Contrast, Exposure
Lens Parameter Standard 3.6mm, optional 2.1/2.5/2.8/6mm/ FOV(D)170 Degree
Audio input Support
IR CUT Connector Support 2P-1.25mm socket
LED board test connector Support 2P-1.25mm socket
LED board power connector Support 2P-2.0mm socket
Power supply USB BUS POWER 4P-2.0mm socket
Power supply DC5V
Operating Voltage 100mA~120mA
Working current -10-70degree
Working temperature -20 to 85degree
Board size /Weight 38X38mm(Compatible 32X32mm)/ about 30g
Cable Standard 1M / optional 2M,3M,5M
Operating system request Win XP/Vista/Win7/Win8
Linux with UVC(above linux-2.6.26)
MAC-OS X 10.4.8 or later
Android 4.0 or above with UVC
Car and ship control, electronic equipment, oil field equipment, industrial equipment, remote site
monitoring, environmental monitoring, etc.
used for all kinds of machine as below:
machinery equipment, all-in-one machine, POS equipment, STB, smart box TV BOX, advisement player, LED display, automatic vending machine, safety box, notebook, video door phone, MID, Tablet external, evaluator, Medical Equipment, on-the-spot law enforcement, door bell and button system, cat-eye system, simple security system, teaching system, Interactive system, automobile data recorder. Project video capture, credit card machine, attendance machine, Voting system, High speed video shooting Device, exam system, Driving learning system, Industrial camera, biological microscope, box inside surveillance, micro HD surveillance, endoscope, Medical auxiliary equipment, etc.
